Kopex KSU Flexible Conduit

Uncovered Stainless Steel Conduit.

Clear

Share this product:

Type KSU

Uncovered Stainless Steel Conduit

  • Stainless Steel AISI 316L
  • Temperature range – Static applications: -50ºC to +300ºC
    Temperature range – Dynamic applications: -45ºC to +250ºC
  • Up to IP40 rating (with appropriate fitting)
  • Very high flexibility and fatigue life

Typical applications

  • General OEM Machinery
  • Lighting / Cable Track
  • Under-floor wiring, access flooring

Approvals

  • BSI Kitemark KM-90009
  • CE Mark to the Low Voltage Directive
Part No.Nominal Conduit SizeUS
Conduit Size
Outside DiameterInside
Diameter
Coil
Lengths
KSU01*10mm1/4”9.6mm7.0mm10/30m
KSU02*12mm5/16”12.8mm10.0mm10/30m
KSU03*16mm3/8”16.1mm12.9mm10/30m
KSU04*20mm1/2”20.2mm17.0mm10/30m
KSU05*25mm3/4”24.7mm21.1mm10/30m
KSU06*32mm1”32.0mm28.4mm10/20m
KSU07*40mm1 1/4”40.0mm36.4mm10/20m
