Raychem Raystat EX-04 Electronic Trace Heating Thermostat

POA

Ambient Sensing, Electronic

Please enter a quantity

Share this product:

OVERVIEW

The units can be supplied at nominal voltages of either 110 V 50/60 Hz or 230 V 50/60 Hz and has a double pole switch rated at 16 A. The switch contacts can be arranged to be volt free. The temperature setting is set via digital thumb wheel switches inside the enclosure. The thermostat is supplied with a PT100 sensor mounted in a wind shield housing.

TECHNICAL SPECIFICATIONS
Area of useHazardous area: Zone 1 or Zone 2 (Gas) or Zone 21 or Zone 22 (Dust) &Ordinary
Temperature range0°C to 49°C
Ambient temperature range–50°C to +55°C
Output relayDual pole change overtype (DPDT) (optional volt free)
Switching capacity16 A 110 Vac ±10% 50/60 Hz resistive load
Supply voltage110 Vac ±10% 50/60 Hz  230/253 Vac ±10% 50/60 Hz
Switching capacity230/253 Vac ± 10% 50/60 Hz
