MEDC DB14 Loudspeaker

POA

Up to 15 Watts for Harsh Industrial & Marine Environments

Please enter a quantity

Share this product:

DB14 Range – Loudspeakers – Up to 15 Watts

This range of loudspeakers has a power rating of 15 Watts and is suitable for use in demanding environments where a robust construction and high ingress protection rating is required.

The body is manufactured completely from a UV stable glass reinforced polyester which is also highly flame retardant and impact resistant. Stainless
steel screws are incorporated thus ensuring a corrosion free product.

MEDC can also provide a range of speakers suitable for use in potentially explosive atmospheres.

Features

  • IP66 and IP67.
  • Temperature range: –55ºC to +70ºC.
  • Corrosion resistant GRP.
  • 117dBA at 15 watts at 1 metre.
  • 100V line transformer.
  • Power tappings, via integral transformer.
  • Addressable capability.
  • Stainless steel ratcheted mounting bracket.
  • Earth continuity available.
  • BS5839 part 8 compliant version available.
Technical Specification
Area ClassificationWeatherproof.
Ambient Operating Temperature-55°C to +70°C
Ingress ProtectionIP66 & IP67
MaterialCorrosion-free GRP
Output107 dBA at 1W at 1 metre
117 dBA at 15W at 1 metre
Entries2 x 20mm
Weight2.6kg
Tappings15, 7.5, 5, 4, 2, 0.8
OptionsColour, tag & duty labels, transformer voltage,
BS 5839 part 8 compliance, earth continuity

MEDC DB14 Loudspeaker
