Victor Monarch VL14 Pendant
| Std. Cat Ref. | Wattage | Lamp Type | Lampholder |
| MONN/125/MV | 125W | Mercury Vapour | E27 |
| MONN/070/HS | 70W | HPS | E27 |
Features and Benefits
- Easy to install and maintain
- Suitable for pendant or 45° mounting
- Integrated glass retaining mechanism
Weight
Discharge lamp versions – 6.3Kg.
GLS/MBTF versions – 4.8Kg.
Suspension
Mounting strap suitable for two Ø8mm fasteners on 228mm centres.
Power Supply
HID: 220V / 230V / 240V / 254V
GLS: 250V (MAX)
Maximum lamp holder current rating: 4A.
Power Factor
Better than 0.85.
Terminals
3 core up to 2.5 mm2 conductors with looping. Through wiring facility as standard. Terminals for live, neutral & earth are provided. External earth is an option.
Cable Entries
3 x M20 cable entries. Supplied with 1 x transit plug and 2 x blanking plugs.
Cable entry devices (i.e. glands) must maintain the IP rating of the luminaire.
Materials
Main Body LM6 aluminium – with epoxy paint finish.
Cast Iron also available.
Lamp glass Borosilicate glass.
(prismatic pattern).
External fasteners Stainless steel.
