Hawke 501/423 Cable Gland

Flameproof Exd / Increased Safety Exe / Dust Extb double compression seal cable gland for unarmoured cable

Clear

Share this product:

The 501/423 cable gland provides two independent seals on non-armoured elastomer and plastic insulated cables. The first is a flameproof seal on the inner or outer cable sheath, with an additional IP seal on the outer sheath. The cable gland is dual certified Exd and Exe and is suitable for installation in Zone 1 (21) and Zone 2 (22) hazardous areas.

  • Provides superior cable retention to standard unarmoured cable glands with seals at two independent points.
  • When used in increased safety applications, this cable gland may be used with braided cable where the braid and the outer sheath pass into the enclosure.
  • The braid must be suitably terminated inside the enclosure.

Ordering Format [ Gland Type / Size / Male Thread / Female Thread / Material / Options]; Example: 501/423 / C/ M32/ Brass; Example with alternative seal option: 501/423 / C / 1 1¼” NPT /Brass / S

General
ApplicationSuitable for use in Zone 1, Zone 2, Zone 21, Zone 22 and in Gas Groups IIA, IIB and IIC.
Ingress Protection
  • IP66
  • IP67
  • IP68
  • Deluge Protected to DTS01
MaterialBrass (standard); Nickel Plated Brass; 316 Stainless Steel or Aluminium; Brass NPT entries are nickel plated as standard
Operating Temparature Range Celcius-60°C to +100°C
SeriesGroup II, Dual Certified, Hazardous Area Cable Glands
Type
  • Exdb
  • Exeb
  • Extb
Certifications and Compliance
ATEX File NumberBaseefa06ATEX0056X
Certified Listed
  • IEC/EN 60079-0
  • IEC/EN 60079-1
  • IEC/EN 60079-7
  • IEC/EN 60079-31
Hazardous Rating(s)
  • Exd IIC Gb
  • Exe IIC Gb
  • Extb IIIC Db
IECEx File NumberIECEx BAS 06.0013X
IP Rating
  • IP66
  • IP67
  • IP68
Industry Standard(s)
  • IEC/EN 60079-0
  • IEC/EN 60079-1
  • IEC/EN 60079-7
  • IEC/EN 60079-31
Nema Rating4X

501 423 Cable Gland Datasheet
