Hawke PSG/421 Cable Gland

POA

Flameproof, Increased Safety, Dust Protection. Certified ATEX / IECEx

Please enter a quantity

Share this product:

The PSG/421 dual certified Exe/Exd gland offers an instant barrier seal around individual cables, with each pre-punched hole in the silicone seal accepting a wide variance of cable diameters. This results in unparalleled speed of installation, inspection and flexibility, with no need for compounds or resin to achieve the Exd barrier seal, no curing time and instant gland completion. Each gland allows for multiple cables to be fitted into a single entry

  • Unique pre-punched silicone barrier seal, provides a barrier seal to individual cables, allowing multiple cables to enter through a single entry. No putty, resin or compound required to achieve an Exd flameproof barrier seal. Unused holes are to be fitted with the hole plugs provided
  • Rounded Cable entry to prevent cable damage
General
ApplicationSuitable for use in Zone 1, Zone 2, Zone 21 and Zone 22
Ingress ProtectionIP66, IP67 to IEC/EN 60529
Operating Temperature-60°C to +80 °C
SeriesHazardous Area Cable Glands
Certifications and Compliance
ATEX File NumberCML19ATEX1167X and IECEx CML 19.0045X
CertificationIEC/EN 60079-0, IEC/EN 60079-1, IEC/EN 60079-7 and IEC/EN 60079-31
Hazardous Rating(s)
  • Flameproof Ex db IIC Gb, Increased Safety Ex eb IIC Gb and Dust Extb IIIC Db Ex II 2GD
  • DTS01

PSG 421 Cable Gland Datasheet
