Hawke ICG 653/UNIV/L Cable Gland

Barrier Cable Gland with integral armour/braid termination, lead sheath grounding and backnut compression seal. ATEX/IECEx Group II Exd/Exe/ExnR/Ext approved for hazardous areas.

Please enter a quantity

Share this product:

The ICG/653/Universal Cable Gland is a Group II certified barrier cable gland suitable for installation in Zone 1/21 and Zone 2/22 hazardous areas. Dual Certified ATEX/IECEx (along with many more) for use in Increased Safety (Exe), Flameproof (Exd), Restricted Breathing (ExnR) and Dust (Ext) Zone protection concepts. Integral grounding ring suitable for single wire armour ‘W’, wire braid ‘X’ and tape armour ‘Z’. Suitable for both elastomer and plastic insulated cables, and particularly for cables which have a lead inner sheath. The gland features a unique fully inspectable transparent elastomeric compound chamber The gland also provides an elastomeric seal on the cable inner sheath, and a low smoke, zero halogen IP and retention seal onto the cable outer sheath.

  • Metallic body construction
  • Fully Inspectable Elastomeric Compound Chamber
  • Available with either ExPress (liquid resin) or QSP (2-part hand mix compound), both with a cure time of 30 minutes
  • Integral electrical bond to lead inner sheath
  • Reversible Armour Clamp – For all types of armour and braid
  • Patented Cable Gland Tightening Guide – Helps prevent damage caused by over tightening
  • Unique Rear Seal – Offering ultimate sealing over an extremely wide cable acceptance range
  • Inspectable Deluge Seal – Offering IP66, IP67, IP68 & IP69 Ingress Protection
  • Available with metric or NPT entry threadforms

ApplicationHazardous Areas Zone 1, Zone 21, Zone 2, Zone 22
Ingress Protection
  • IP66, IP67, IP68 (30 metres for 7 days, special instruction apply)
  • IP69 to IEC/EN 60529
  • NEMA 4X
  • Deluge Protection to DTS01
MaterialManufactured in Brass, Nickel Plated Brass or 316L Stainless Steel
Operating Temperature-60°C to +80 °C
SeriesCable Glands for Group II Hazardous Areas


Certifications and Compliance
ATEX File NumberCML 18ATEX1268X, CML 19ATEX4507 (Ex nR)
CSA File Number1024328
  • ATEX: CML 18ATEX1268X / CML 19ATEX4507 (Ex nR)
  • CCC: 2020312313000317
  • cCSAus: 1024328
  • DNV: TAE0000BS
  • EAC: No EA3C RU C-GB.HA91.B.00264/21
  • EQM: 20-11-27224/Q20-11-000979/NB0007
  • IECEx: CML 18.0131X / CML 21.0012X (Ex nR)
  • Inmetro: IEx 14.0272X
  • KCs: 17-KA4BO-0159X to 0167X
  • PESO: P450038
  • SONCAP: LCOGB049552-0500
  • UKEx: CML 21UKEX1132X / CML 21UKEX4133X (Ex nR)
Hazardous Rating(s)
  • Ex II 2GD Ex db IIC Gb
  • Ex eb IIC Gb
  • Ex nR IIC Gc
  • Ex tb IIIC Db
  • Class I Div 1 ABCD
  • Class II Div 2 EFG and Class III
  • Class I, Zone I, AEx db IIC Gb
  • AEx eb IIC Gb
  • Zone 21, AEx tb IIIC Db
IECEx File NumberCML 18.0131X
Industry Standard(s)
  • IEC/EN 62444 (Anchorage Type D)
  • IEC/EN 60079-0, 1, 7, 15, 31
  • CSA 60079-0, 1, 7, 31
  • CSA C22.2 No. 0-10, CSA C22.2 No. 174-18
  • UL2225
  • UL1203
  • UL514B
RatingsIK10 to IEC 62262

ICG 653/UNIV/L Cable Gland Datasheet
