Kopex FLH Flexible Conduit

High Temperature – Liquid Tight Conduit.

Clear

Share this product:

Type FLH

High Temperature – Liquid Tight Conduit

  • Galvanised Steel Core – String packed with thermoplastic rubber covering
  • Flame dies in less than 30 seconds after ignition source is removed
  • Temperature range – Static applications: -50ºC to +130ºC
    Temperature range – Dynamic applications: -45ºC to +130ºC
  • Up to IP67 rating (with appropriate fitting)
  • High UV resistance
  • High flexibility – high fatigue life
  • Halogen free
  • Self extinguishing

Typical applications

  • Utility – Power Generation
  • Rail Traction – low temperature flexing

Approvals

  • BSI Kitemark KM-90009
  • CE Mark to the Low Voltage Directive
Black
Part No.
Blue
Part No.
Nominal Conduit SizeUS
Conduit Size
Outside DiameterInside
Diameter
Coil Lengths (m)
FLH03*FLLH0316mm3/8”17.8mm12.5mm10, 30
FLH04*FLLH04*20mm1/2”21.1mm15.9mm10, 30
FLH05*FLLH05*25mm3/4”26.4mm21.0mm10, 30
FLH06*FLLH06*32mm1”33.1mm26.7mm10, 30
FLH07*FLLH07*40mm1 1/4”41.8mm35.4mm10, 30
FLH08*50mm1 1/2”47.5mm40.4mm10, 30
FLH09*63mm2”59.7mm51.6mm10, 30
