Kopex XSM 90° Elbow Fitting

90° Elbow Fitting – External Male Thread

Clear

Share this product:

Type XSM 90°

90° Elbow Fitting – External Male Thread

  • Nickel plated brass
  • UL514B File No. E60625 listed
  • Temperature range – Static Applications: -50ºC to +150ºC
    Temperature range – Moving Applications: -50ºC to +150ºC
  • High Temperature Co-polyester Seal
  • IP66 to IP69 rated
  • For insertion into threaded entries & knockouts using a locknut (order locknut separately)

Typical applications

  • Industry Processing – Food and beverage, chemical, feed, wood
  • Automation, machines & panel building
  • Utility – Power
  • Mining equipment
  • Marine & Shipping

Approvals

  • BSI Kitemark KM-90009
  • CE Mark to the Low Voltage Directive
  • UL514B file number E60625
Metric Part No.Nominal Conduit SizeMetric Thread SizeNPT
Part No.
NPT
Thread Size
US
Conduit Size
XSM030316mmM163/8”
XSM030420mmM20XSA03041/2”3/8”
XSM040420mmM20XSA04041/2”1/2”
XSM050525mmM25XSA05053/4”3/4”
XSM060632mmM32XSA06061”1”
XSM070740mmM40XSA07071 1/4”1 1/4”
XSM080850mmM50XSA08081 1/2”1 1/2”
XSM090963mmM63XSA09092”2”
