Kopex GFM Fitting

Straight Fitting – Fixed External Male Thread for Uncovered Conduit.

Clear

Share this product:

Type GFM

Straight Fitting – Fixed External Male Thread for Uncovered Conduit

  • Zinc & Nickel plated brass
  • Temperature range – Static Applications: -50ºC to +350ºC
    Temperature range – Moving Applications: -45ºC to +250ºC
  • IP40 rated
  • For insertion into threaded entries & knockouts using a locknut (order locknut separately)

Typical applications

  • General OEM Machinery
  • Lighting / Cable Track
  • Under-floor wiring, access flooring
Approvals
  • BSI Kitemark KM-90009
  • CE Mark to the Low Voltage Directive
Part No.Metric
Thread Size
Ext. Thread
Outside Diameter
GFM0303*M1616mm
GFM0304**M2020mm
GFM0404**M2020mm
GFM0505**M2525mm
GFM0606**M3232mm
GFM0707*M4040mm
GFM0808*M5050mm
