CEAG AB50 Pendant Fitting

Incandescent Pendant fitting suitable for Zones 1, 2, 21 & 22

Clear

Share this product:
The pendant light fitting series for a wide variety of applications

The explosion-protected pendant light fittings for incandescent and energy-saving lamps, high intensity discharge and induction lamps can be used with their different housing solutions
in different areas. The robust flameproof luminaires have been in use in many industrial plants for many years and have stood the test of time.

AB 50 / SPG 1N and AB 51

This larger series of pendant light fittings is suitable for incandescent and mixed-light lamps. The robust light alloy enclosure allows a wide range of applications. The protective glass dome is made of borosilicate glass and is extremely impact and heat resistant. The reflector and all external screws are made of stainless steel. Easy replacement of lamps is made possible by opening the
PTFE-coated connection ring. Both devices (the protective glass dome and connection ring) are provided with hinges to allow easy access. Thanks to their robust design, these light fittings are suitable for use in the chemical industry and are certified for ambient temperatures from – 55 ° C to + 55 ° C.

EVI the powerful pendant light fitting series

This larger series of pendant light fittings is suitable for incandescent and mixed-light lamps. The robust light alloy enclosure allows a wide range of applications. The protective glass dome is made of borosilicate glass and is extremely impact and heat resistant. The reflector and all external screws are made of stainless steel. Easy replacement of lamps is made possible by opening the
PTFE-coated connection ring. Both devices (the protective glass dome and connection ring) are provided with hinges to allow easy access. Thanks to their robust design, these light fittings are suitable for use in the chemical industry and are certified for ambient temperatures from – 55 ° C to + 55 ° C.

Features
  • Different housing solutions with different light sources for nearly every application
  • Robust design for harsh environments
  • With large Ex-d or Ex-e terminal compartment
  • Wide ambient temperature range depending on the version from -50 °C up to +55 °C
  • CU-Certificate for Eurasian Economic Community available
  • High degree of protection IP 66
  • Meets the highest corrosion protection and mechanical strength requirements
AB 50
EC-Type Examination CertificateLOM 02 ATEX 2018 X
IECEx Certificate of ConformityIECEx BKI 07.0032X
Marking accd. to 2014/34/EUD II 2 D Ex d/de IIC T3 / T6
D II 2 D Ex tD A21 IP66 T ..°C
Marking accd. to IECExEx d IIC T3…T6 or Ex de IIC T3…T6 (indirect entry)
Ex tD A21 IP66 T145°…T85°C
Permissible ambient temperature-20 °C up to +55 °C
-50 °C up to +55 °C (option: AB 50)
Rated voltagemax. 250 V
Frequency50 Hz
Power consumptionmax.100 VA
Protection classI
Lamp / Illuminant60 W, 100 W, 75 W halogen
Rated luminous flux1)
Lamp capE27 accord. IEC 60238
Light output ratio68 %
Connecting terminalsL, N, PE: 1 x 2.5 mm2 or 2 x 1.5 mm2,
PE ext. 2 x 6 mm2
Enclosure colourepoxy paint, body RAL 7032
Enclosure materiallight alloy
Weight1.6 kg
Cable glands / gland plates /
enclosure drilling
2 x 3/4” or M25 thread (Ex-d),
1 x plugged (UI and M/S) /
2 x M25 x 1.5, 1 x plugged (IX)
Type of mountingceiling-/wall mounting (AB 50), portable light fixture (SPG 1N)
Degree of protection accd. to EN 60529IP66
Protective cover / protective bowlborosilicate glass
1) see table luminaire data

CEAG AB50 Pendant Fitting Datasheet
