CEAG AB80 11W Bulkhead Fitting

Incandescent Wall & Ceiling light suitable for Zones 1, 2, 21 & 22

Clear

Share this product:
AB 80 – the standard solution

This light fitting can be fitted with incandescent lamps with an E27 socket up to 100 W and is used as a wall or ceiling light in the chemical industry. Due to the robust enclosure and the ambient temperature range up to +55°C, this light fitting is suitable for a wide variety of applications.

Features
  • Extremely rugged design for extremely harsh environments
  • Wide ambient temperature range depending on the version (-55 ° C to +55 ° C )
  • High degree of protection up to IP 67
AB 80
EC-Type Examination CertificateLOM 01 ATEX 2041 X
Marking accd. to 2014/34/EUD II 2 G Ex d IIB T4.. T6 Gb
Permissible ambient temperature-20 °C up to +55 °C
Rated voltagemax. 250 V
Protection classI
Lamp / IlluminantIncandescent lamp
Lamp capE27
Light output ratio60 %
Dimensions (L x W x H)282 x 205 x 150 mm
Connecting terminalsL1, N, PE: 2 x 2.5 mm2
Enclosure earth2 x 6 mm2
Enclosure colourEpoxy paint, body RAL 7032
Enclosure materialcast iron
Weight6.6 kg
Cable glands / gland plates /
enclosure drilling
2 x M25 x 1.5 or 2 x 3/4’’ NPT (with adaptor)
Type of mountingceiling/wall mounting
Degree of protection accd. to EN EN 60598IP65
Protective cover / protective bowlborosilicate glass
Screw plugs1 x M25 or 3/4’’ NPT Ex-d screw plug
1) depends on used lamps
