Eaton Crouse-Hinds ExLin LED Linear Light Fitting

ExLin – The new way of lighting in hazardous areas

Suitable for Zone 1,2,21 and 22

Clear

Share this product:

ExLin – LED Luminaires

for hazardous areas

ExLin Series
Safe, Reliable, Efficient
(Zone 1, 2)
The efficient solution for your explosion-protected lighting applications

The explosion-protected ExLin series of luminaires is the first explosion-protected series of LED linear luminaires in a modular plastic design. This installation-friendly series of luminaires is efficient, easy to maintain, versatile and robust and, as such, the ideal solution for lighting tasks within harsh and hazardous environment.

Innovative lighting technology for a modular lighting concept

We, a leading manufacturer of explosion-protected luminaires, have created a completely new type of adaptable linear LED luminaire, the ExLin. With light outputs from 2750 lm to 8120 lm, this series of luminaires can be used for almost all lighting concepts. Thanks to the various optics it is possible to create a tailor-made lighting for even the most difficult spaces. In addition, the large temperature range from -40 °C to +55 °C allows their use in various climatic zones and under difficult ambient conditions.

The design and approvals of the luminaires allow their use in hazardous areas in Zone 1, 2, 21 and 22 in the tried-and-tested type of protection Ex e. Thanks to the generously dimensioned and easily accessible terminal compartment, connection is easy.

Advantages of the modular design:
  • 4 different types of luminaires with 3 different optics, 4 different covers and one enclosure concept
  • Forward-looking modular concept
Easy maintenance:
  • The modules are plugged into the enclosure and can also be replaced easily inside the hazardous area. The ballast is freely accessible.
  • Easy modification in the event of a change in use of an existing installation.
Simple and cost-effective installation

As is standard with all other CEAG brand linear luminaires, our ExLin series feature a single-end through-wiring that, together with the generously dimensioned terminal compartment, allows a cost-effective installation.

Service life

The expected service life of our LED module is L90 ~100.000 h at +25 °C. This is a significant improvement compared to previous lighting solutions.

Specially designed cooling elements for the dissipation of heat from the LEDs ensure a long service life and a higher luminous efficiency.

Features
  • Modular design and Ex-e technology for easy servicing and maintenance
  • Tried-and- tested technology – the driver and materials have been used for more than 20 years
  • Various optics for an optimum illumination
  • Extremely long service life of LEDs and drivers
  • LED module and driver have U-certification for hazardous areas
  • For ambient temperatures from -40 °C to +55°C

Suitable lighting for all applications
  • Light output range from 2750 lm to 8120 lm, replaces up to 2×58 W fluorescent linear luminaires
  • Various optics available for an optimum illumination of your application (standard, wide and narrow beam)
  • Available with clear or opaque cover
Sophisticated design
  • Enclosure design and surface structure for the avoidance of water and dust deposits
  • Compact, slim design saves weight and space
Robust luminaire for every application
  • Temperature range from -40 °C to +55 °C
  • For hazardous areas in Zone 1, 2, 21 and 22
Easy replacement without changing the connection and mounting points
  • Replacement of existing eLLK linear luminaires, 2×18 W, 2×36 W, 2×58 W with mounting kit
Easy servicing extends the service life and minimizes the ecological footprint
  • Replaceable control gear and LED module
  • Maintenance-friendly enclosure; driver easily accessible
Exceptional efficiency
  • Up to 120 lm/W
  • Power factor > 0.9 for the entire series of luminaires
Durability
  • Service life L90 at 100,000 h
ExLin3L-1ExLin5L-1ExLin7L-2
EC-Type Examination Certificaterequestedrequestedrequested
IECEx-Certification of conformityrequestedrequestedrequested
Marking accd. to 2014/34/EUEx II 2 G Ex eb ib q op is IIC T4 Gb
Ex II 2 D Ex tb IIIC T80°C Db IP66
Ex II 2 G Ex eb ib q op is IIC T4 Gb
Ex II 2 D Ex tb IIIC T80°C Db IP66v
Ex II 2 G Ex eb ib q op is IIC T4 Gb
Ex II 2 D Ex tb IIIC T80°C Db IP66
Marking accd. to IECExEx eb ib q op is IIC T4 Gb
Ex tb IIIC T80°C Db
Ex eb ib q op is IIC T4 Gb
Ex tb IIIC T80°C Db
Ex eb ib q op is IIC T4 Gb
Ex tb IIIC T80°C Db
Permissible ambient temperature-40 °C up to +55 °C with glass cover
-25 °C up to +55 °C with polycarbonate cover
-40 °C up to +55 °C with glass cover
-25 °C up to +55 °C with polycarbonate cover
-40 °C up to +55 °C with glass cover
-25 °C up to +55 °C with polycarbonate cover
Life expectancy control gearC5 ~100,000 h at ta = +25 °C
C10 ~75,000 h at ta = +55 °
C5 ~100,000 h at ta = +25 °C
C10 ~75,000 h at ta = +55 °C
C5 ~100,000 h at ta = +25 °C
C10 ~75,000 h at ta = +55 °C
Life expectancy LEDL90 ~100,000 h at ta = +25 °C
L85 ~75,000 h at ta = +55 °C
L90 ~100,000 h at ta = +25 °C
L85 ~75,000 h at ta = +55 °C
L90 ~100,000 h at ta = +25 °C
L85 ~75,000 at ta = +55 °C
immunity to surge voltages according to EN6100-4-54 kV, L-N and L-PE4 kV, L-N and L-PE4 kV, L-N and L-PE
Rated voltage110 up to 254 V AC/DC110 up to 254 V AC/DC110 up to 254 V AC/DC
Frequency0/50 – 60 Hz0/50 – 60 Hz0/50 – 60 Hz
Power consumption22 W44 W67 W
Power factor cos ϕ @ 230 V≥ 0.92≥ 0.95≥ 0.95
CircuitEVGEVGEVG
Protection classIII
Lamp / illuminantLED systemLED systemLED system
Rated luminous flux of the luminaire
(typical, ±10 %)*
clear protective cover: 2750 lm
frosted protective cover: 2370 lm
clear protective cover: 5300 lm
frosted protective cover: 4580 lm
clear protective cover: 8120 lm
frosted protective cover: 6920 lm
Light colour / CRI5000 K / 70 (80 on request)5000 K / 70 (80 on request)5000 K / 70 (80 on request)
Dimensions (L x W x H)770x201x115 mm770x201x115 mm931x201x115 mm
Enclosure colourgrey/blackgrey/blackgrey/black
Enclosure materialGlassfibre reinforced polyesterGlassfibre reinforced polyesterGlassfibre reinforced polyester
Weight6.7 kg6.7 kg8.0 kg
Degree of protection accd. to EN 60529IP66/67IP66/67IP66/67
Protective cover / protective bowltoughened glass/ Polycarbonate,
clear or opaque
toughened glass/ Polycarbonate,
clear or opaque
toughened glass/ Polycarbonate,
clear or opaque
OpticStandard, narrow beam, wide beamStandard, narrow beam, wide beamStandard, narrow beam, wide beam

Type Key

ExLin
