Hawke CSB 656N Cable Gland

Flameproof Exd / Increased Safety Exe / Dust Extb barrier type conduit cable gland

Clear

Share this product:

The CSB 656N cable gland provides a barrier type seal (compound) around each individual core installed in conduit. The cable gland is dual certified Exd and Exe and is suitable for installation in Zone 1 (21) and Zone 2 (22) hazardous areas.

  • Cable inner sheaths that are not effectively filled, compact and/or circular, have tape bedding or have hygroscopic fillers.
  • Cables that exhibit ‘cold flow’ characteristics.
  • Enclosures containing an ignition source in gas group IIC areas or containing an ignition source in a Zone 1 area.
  • Provides a barrier seal between the individual insulated cores within the cable and prevents entry of the products of an explosion into the cable or conduit.
  • Seals conductors at entry to enclosure via conduit or enables an existing cable gland to be converted to a barrier type cable gland.
  • The device is fitted with a simple compound filled chamber which permits packing around individual insulated conductors.
  • Assembly of the cable gland compresses and distributes the compound evenly to create a barrier seal at the point of entry into the enclosure.
  • The compound chamber may be separated from the cured compound to ensure that the chamber has been effectively filled.
  • If required, external voids can be repaired.

Provides female running coupler for cable gland or conduit entry.
Ordering Format [ Gland Type / Size / Male Thread / Female Thread / Material / Options]; Example: CSB/656N / C/ M32/ M32 /Brass

General
ApplicationSuitable for use in Zone 1, Zone 2, Zone 21, Zone 22 and in Gas Groups IIA, IIB and IIC.
Ingress Protection
  • IP66
  • IP67
  • IP68
  • Deluge Protected to DTS01
MaterialBrass (standard); Nickel Plated Brass; 316 Stainless Steel or Aluminium; Brass NPT entries are nickel plated as standard
Operating Temparature Range Celcius-60°C to +80°C
SeriesGroup II, Dual Certified, Hazardous Area Cable Glands
Type
  • Exdb
  • Exeb
  • Extb
Certifications and Compliance
ATEX File NumberBaseefa06ATEX0058X
Hazardous Rating(s)
  • Exd IIC Gb
  • Exe IIC Gb
  • Extb IIIC Db
IECEx File NumberIECEx BAS 06.0015X
IP Rating
  • IP66
  • IP67
  • IP68
Nema Rating4X

CSB 656N Cable Gland Datasheet
