Hawke FireMate A2 Cable Gland

POA

Please enter a quantity

Share this product:

A fire resistant, robust and simple design for applications using non armoured cable in a heavy industrial, critical safety environment which is exposed to dust or extreme weather conditions. All cable glands can be supplied with a shroud, lock nut, serrated washer and an earth tag.

Features

Combining market-leading design and fireproof technology, the Firemate A2 Gland boasts a range of exceptional features:

  • Provides a cable retention seal onto the cables outer sheath
  • Simple robust single compression cable gland construction
  • Easy of Assembly
  • High quality materials with exceptional anti corrosion properties
  • UV stable seal
  • Tested to the latest industrial standards
General
Construction and Test Standards:
  • BS EN 62444:2013
  • BS6121: Part 1 type A2
Ingress Protection
  • IP66 IEC/EN 60529
MaterialNickel Plated Brass with Intumescent Rubber Seal
Operating TemperatureRange: -20°C to +70°C
Clamping ArrangementSingle compression seal
Cable TypeNon armoured
Kit InformationIntumescent sealing material used for FireMate versions
Note: Displacement or Compression seals do not prevent cold flow. IP seal required to maintain IP66.

FireMate A2 Cable Gland Datasheet
